Power Supply: 400V, 50Hz

Rated Cooling Capacity: 15.26 kW up to approx. 95 kW

Total Power Consumption: 5.84 kW up to approx. 20 kW

Compressor Type: Rotary Compressor up to Dual Scroll Compressor

Refrigerant: R410a

Noise Level: ＜78–81 dB(A)

Pump Power: 0.37 kW up to 3 kW

Pump Head: 30–50 m

Flow Rate: 30–160 L/min

Ambient Temperature: ＜40 °C

Water Temperature Range: 8–30 °C

Temperature Accuracy: ±0.5 °C up to ±1 °C

Tank Capacity: 60–200 L

Water Inlet/Outlet Connection: Rp3/4” up to Rp1 1/2” / DN40

Evaporator Type: Coil Evaporator in Water Tank up to Stainless Steel Plate Heat Exchanger

Expansion System: Capillary Tube up to Thermostatic Expansion Valve

Cooling Control: Intelligent PID Control

Dimensions (L×W×H): 627 × 1270 × 1264 mm up to approx. 1600 × 900 × 1700 mm

Net Weight: 215 kg up to approx. 550 kg
